BỘ ĐIỀU KHIỂN VAN DANFOSS EKE 2U - C/N 080G5555

Gross weight

0.3 Kilogram

Net weight

0.25 Kilogram

EAN

5714279874402

Type

EKE 2U

Product group

Electronic controllers

Product Name Description

Backup power module

Ambient temperature range [°C] [max]

60 °C

Ambient temperature range [°C] [min]

-25 °C

Analog inputs (AI) [pc]

0 pc

Analog outputs (AO) [pc]

0 pc

Approval

CE; RoHS; UL

Battery back-up [V] DC

24 V

CE evaluated

Yes

China RoHS compliance

Out of scope

Communication type

Digital output

Contain batteries

No

Digital inputs (DI) [pc]

0 pc

Digital outputs (DO) [pc]

1 pc

Display - option

None

Display on front

No

Enclosure rating note

IP40 for Housing

EU RoHS compliance

Out of scope

Frequency [Hz]

50/60 Hz

Further information

Maximum nominal output current

Max. current output/phase [A]

2 A

Mounting method

DIN rail

Number of pressure sensors

0

Number of Sensor inputs

0 pc

Number of temperature sensors

0

Other RoHS documentation

EAEU RoHS

Packing format

Multi pack

Power consumption [VA]

15 VA

Product accessories

Electron. control accessories

Product features

Backup power for up to 2 EKE 1
LEDs showing status: Charging
LEDs showing status: Failed
LEDs showing status: Ready
LEDs showing status: Replace
Shared power supply
State of Health detection
Status output signal: Charging
Status output signal: Failed
Status output signal: Ready
Status output signal: Replace

Product Language

English

Quantity per packing format

24 pc

REACH Candidate List substances

Lead (CAS no. 7439-92-1)

SCIP dossier no.

a943317a-3b9b-4eed-903d-d6796f9eb724

Serviceable

No

Supply voltage [V] AC

24 V

Supply voltage [V] DC

24 V

UL evaluated

Yes

Used for product

EIM 365
EKD 316
EKD 316C
EKE 1A
EKE 1B
EKE 1C
EKE 1D
MCX061V
MCX152V
