CÔNG TẮC DÒNG CHẢY DANFOSS FQS - C/N 061H4002

Gross weight

0.654 Kilogram

Net weight

0.6 Kilogram

Volume

1.976 Liter

EAN

5702428275385

Ambient temperature range [°C] [max]

80 °C

Ambient temperature range [°C] [min]

-25 °C

Ambient temperature range [°F] [max]

176 °F

Ambient temperature range [°F] [min]

-13 °F

Approval

CE; UKCA

Burst pressure [bar]

48 bar

Burst pressure [psig]

696 psig

CE evaluated

Yes

China RoHS compliance

Out of scope

Connection type

Thread

Contact function

SPDT

Contain batteries

No

Decr adj DN100/4 in [l/min] [max]

940 l/min

Decr adj DN100/4 in [l/min] [min]

200 l/min

Decr adj DN125/5 in [l/min] [max]

1120 l/min

Decr adj DN125/5 in [l/min] [min]

350 l/min

Decr adj DN150/6 in [l/min] [max]

1700 l/min

Decr adj DN150/6 in [l/min] [min]

530 l/min

Decr adj DN25/1 in [l/min] [max]

45 l/min

Decr adj DN25/1 in [l/min] [min]

18 l/min

Decr adj DN32/1-1/4 in [l/min] [max]

100 l/min

Decr adj DN32/1-1/4 in [l/min] [min]

43 l/min

Decr adj DN40/1-1/2 in [l/min] [max]

140 l/min

Decr adj DN40/1-1/2 in [l/min] [min]

63 l/min

Decr adj DN50/2 in [l/min] [max]

250 l/min

Decr adj DN50/2 in [l/min] [min]

50 l/min

Decr adj DN65/2-1/2 in [l/min] [max]

565 l/min

Decr adj DN65/2-1/2 in [l/min] [min]

105 l/min

Decr adj DN80/3 in [l/min] [max]

850 l/min

Decr adj DN80/3 in [l/min] [min]

100 l/min

Enclosure rating IP

IP20

EU RoHS compliance

Out of scope

Housing

Regular

Incr adj DN100/4 in [l/min] [max]

950 l/min

Incr adj DN100/4 in [l/min] [min]

210 l/min

Incr adj DN125/5 in [l/min] [max]

1140 l/min

Incr adj DN125/5 in [l/min] [min]

380 l/min

Incr adj DN150/6 in [l/min] [max]

1800 l/min

Incr adj DN150/6 in [l/min] [min]

570 l/min

Incr adj DN25/1 in [l/min] [max]

50 l/min

Incr adj DN25/1 in [l/min] [min]

21 l/min

Incr adj DN32/1-1/4 in [l/min] [max]

102 l/min

Incr adj DN32/1-1/4 in [l/min] [min]

46 l/min

Incr adj DN40/1-1/2 in [l/min] [max]

145 l/min

Incr adj DN40/1-1/2 in [l/min] [min]

68 l/min

Incr adj DN50/2 in [l/min] [max]

255 l/min

Incr adj DN50/2 in [l/min] [min]

58 l/min

Incr adj DN65/2-1/2 in [l/min] [max]

570 l/min

Incr adj DN65/2-1/2 in [l/min] [min]

120 l/min

Incr adj DN80/3 in [l/min] [max]

880 l/min

Incr adj DN80/3 in [l/min] [min]

115 l/min

Max. Flow velocity [m/s]

2 m/s

Max. Working Pressure [bar]

10 bar

Max. Working Pressure [psig]

145 psig

Media

Fresh water; Glycol; Neutral brine

Medium temperature range [°C] [max]

80 °C

Medium temperature range [°C] [min]

5 °C

Medium temperature range [°F] [max]

176 °F

Medium temperature range [°F] [min]

41 °F

Packing format

Multi pack

Piping diameter range Ø [in] [max]

6 in

Piping diameter range Ø [in] [min]

1 in

Piping diameter range Ø [mm] [max]

150 mm

Piping diameter range Ø [mm] [min]

25 mm

Pressure connection size

1 in

Pressure connection type

R

Product accessories

No

Product group

Switches and thermostats

Product Name Description

Flow switch

Quantity per packing format

9 pc

REACH Candidate List substances

No

Serviceable

No

Type

FQS

Type designation

FQS-030G

UK RoHS compliance

Out of scope
