CẢM BIẾN NHIỆT ĐỘ DANFOSS MBT 120 - C/N 097U0181

Mã sản phẩm: 097U0181

Thương hiệu: Danfoss

Giá thị trường: 1 đ

Tiết kiệm: 0 đ (0%)

Giá bán: 1 đ

Số lượng:

Đặt hàng qua điện thoại: Mr Thịnh - 0918808005 / 0937250579

Hoặc gửi email: thinhhh79@gmail.com

CẢM BIẾN NHIỆT ĐỘ DANFOSS MBT 120 - C/N 097U0181

Product details

CE evaluated	Yes
China RoHS compliance	Out of scope
Connection material	Stainless steel
Connection standard	ISO 228
Connection type	G
EEE category	5 small equipment (any external dimension 50 cm)
EU RoHS compliance	Yes with exemptions
Extension length [in]	1.97 in
Extension length [mm]	50 mm
In scope of WEEE	Yes
In scope of WEEE and contain batteries	No
Insertion length [in]	5.9 in
Insertion length [mm]	150 mm
Insertion type	Fixed
Packing format	Multi pack
Process connection Male/Female	Male
Process connection material	Stainless steel
Process connection size	1/2
Process connection standard	ISO 228-1-A
Process connection type	G
Product group	Accessories, sensors
Product Name Description	Sensor pocket
Protection tube diameter [in]	0.394 in
Protection tube diameter [mm]	10 mm
Protection tube material	AISI 316 Ti
Quantity per packing format	20 pc
REACH Candidate List substances	No
Temperature range [°C] [max]	200 °C
Temperature range [°C] [min]	-50 °C
Temperature range [°F] [max]	392 °F
Temperature range [°F] [min]	-58 °F
Type	MBT 120
Type designation	MBT 120-111-150-3
UK RoHS compliance	Out of scope
Used for product	MBT 3252 / MBT 5252
