CÔNG TẮC NHIỆT ĐỘ DANFOSS KPS81 - C/N 060L314966

Gross weight

0.888 Kilogram

Net weight

0.875 Kilogram

Volume

2.73 Liter

EAN

5702423147991

Amb. Temp. Note

80 °C/176 °F for max 120 min

Ambient temperature range [°C] [max]

70 °C

Ambient temperature range [°C] [min]

-40 °C

Ambient temperature range [°F] [max]

158 °F

Ambient temperature range [°F] [min]

-40 °F

Approval

ABS ; BV ; CCC ; CCS ; CE ; DNV ; EAC ; GL ; LLC CDC EURO-TYSK ; LR ; LVD ; NKK ; RINA ; RMRS ; RoHS ; RoHS China ; TYSK ; UKCA ; UL

CE evaluated

Yes

Charge type

Adsorption

China RoHS compliance

Yes

Connection for pocket or hose

M 18 x 1.5

Contact function

SPDT gold

Contact rating

AC15=4 A, 440 V; AC1=10 A, 440 V; AC3=6 A, 440 V; DC13=12 W, 220 V; for gold 1…30mA, 5...30V

Diff. @ Min. range setting [K] [max]

25 K

Diff. @ Min. range setting [K] [min]

5 K

Diff. @ Min. range setting[°C] [max]

25 °C

Diff. @ Min. range setting[°C] [min]

5 °C

Differential type

Adjustable

Electrical conn. comments

Metal cable gland

Electrical conn. Male/Female

Female

Electrical connection

Screwed cable entry

Electrical connection size

Pg 13.5

Electrical connection standard

DIN 40430

Electrical spec. standard

EN 60947-5

EN 60947 electrical properties

Insulation: 400V; Pollution degree: 3; Rated impulse voltage: 4 kV; Short circuit prot, fuse: 16A

EN 60947 wiring properties

Flex, ferrules: 0.5-1.5 mm2; Flex, no ferrules: 0.7-2.5 mm2; Solid/stranded: 0.75-2.5 mm2

Enclosure rating IP

IP67

EU RoHS compliance

Out of scope

In scope of WEEE and contain batteries

No

Max. sensor temperature [°C]

250 °C

Max. sensor temperature [°F]

482 °F

Packing format

Multi pack

Product accessories

Switches accessories

Product description

Thermostat

Product group

Switches and thermostats

Product Name Description

Thermostat

Quantity per packing format

8 pc

REACH Candidate List substances

Lead (CAS no. 7439-92-1)

Reset function

Auto

SCIP dossier no.

84be8326-1b95-4f87-afb0-90ae08b65f06

Sensor pocket length min. [in]

3 in

Sensor pocket length min. [mm]

75 mm

Sensor size (Ø x L) [in]

1/2 x 2 1/2 in

Sensor size (Ø x L) [mm]

13 x 63 mm

Sensor type

Rigid sensor

Serviceable

No

Temperature range [°C] [max]

150 °C

Temperature range [°C] [min]

60 °C

Temperature range [°F] [max]

302 °F

Temperature range [°F] [min]

140 °F

Type

KPS81

UK RoHS compliance

Out of scope

UL approval file name

E73170

UL evaluated

Yes
