CẢM BIẾN ÁP SUẤT DANFOSS MBS 3000 (MBS 3000-2016-DRAB04-0), 0 - 10bar, 0 - 145psi - C/N 060G6791
Product details
|
Gross weight |
0.366 Kilogram |
|
Net weight |
0.274 Kilogram |
|
Volume |
1.281 Liter |
|
EAN |
5702428582674 |
|
+ output |
Brown |
|
+ supply |
Red |
|
- common |
Black |
|
Accuracy, max. [±FS%] |
1 % |
|
Accuracy, typical [±FS%] |
0.3 % |
|
Adj. zero point and span |
No |
|
Ambient temperature range [°C] [max] |
85 °C |
|
Ambient temperature range [°C] [min] |
-30 °C |
|
Ambient temperature range [°F] [max] |
185 °F |
|
Ambient temperature range [°F] [min] |
-22 °F |
|
Approval |
ATEX |
|
Approval comments |
ATEX Ex ec IIA T4 Gc |
|
Cable length [in] |
118 in |
|
Cable length [m] |
3 m |
|
China RoHS compliance |
Yes exceed limitations |
|
Compensated temp. range [°C] [max] |
80 °C |
|
Compensated temp. range [°C] [min] |
0 °C |
|
Compensated temp. range [°F] [max] |
176 °F |
|
Compensated temp. range [°F] [min] |
32 °F |
|
EEE category |
5 small equipment (any external dimension 50 cm) |
|
Electrical conn. comments |
Screened |
|
Electrical connection |
Cable |
|
Enclosure rating IP |
IP68 |
|
EU RoHS compliance |
Yes with exemptions |
|
EU RoHS exemption clause |
No |
|
Flush diaphragm |
No |
|
High Clipping Level |
98 |
|
In scope of WEEE |
Yes |
|
In scope of WEEE and contain batteries |
No |
|
International Article Number |
5702428582674 |
|
Intrinsically safe |
No |
|
Low Clipping level |
4 |
|
Medium temperature range [°C] [max] |
85 °C |
|
Medium temperature range [°C] [min] |
-40 °C |
|
Medium temperature range [°F] [max] |
185 °F |
|
Medium temperature range [°F] [min] |
-40 °F |
|
Non-linearity BFSL [±FS%] |
0.2 % |
|
Output signal |
Ratio metric |
|
Overload pressure max. [bar] |
60 bar |
|
Packing format |
Multi pack |
|
Pressure connection HEX [mm] |
27 mm |
|
Pressure connection size |
1/4 |
|
Pressure connection standard |
EN 837 |
|
Pressure connection type |
G |
|
Pressure Male/Female |
Male |
|
Pressure range [bar] [max] |
10 bar |
|
Pressure range [bar] [min] |
0 bar |
|
Pressure range [psi] [max] |
145 psi |
|
Pressure range [psi] [min] |
0 psi |
|
Pressure reference |
Gauge (relative) |
|
Product group |
Sensors |
|
Product Name Description |
Pressure transmitter |
|
Pulse-snubber |
No |
|
Quantity per packing format |
8 pc |
|
Ratiometric of Vsupply [%] [max] |
90 % |
|
Ratiometric of Vsupply [%] [min] |
10 % |
|
REACH Candidate List substances |
Lead (CAS no. 7439-92-1) |
|
Response time max. [ms] |
4 ms |
|
SCIP dossier no. |
16d2efc6-64f3-4a4e-ae98-a3fd7ce0218d |
|
SCIP dossier product name |
AKS/MBS |
|
Specification key |
MBS 3000-2016-DRAB04-0 |
|
Supply voltage [V] DC [max] |
6 V |
|
Supply voltage [V] DC [max] |
5.5 V |
|
Supply voltage [V] DC [min] |
5 V |
|
Supply voltage [V] DC [min] |
4.5 V |
|
Type |
MBS 3000 |
|
UK RoHS compliance |
Yes |
