VAN TIẾT LƯU DANFOSS AKV 15-4 - C/N 068F5015

Gross weight

1.59 Kilogram

Net weight

1.383 Kilogram

Volume

6.248 Liter

EAN

5702422187202

Actuator system [mm]

13.5 mm

Ambient temperature

-40 - 50 °C

Ambient temperature range [°F] [max]

120 °F

Ambient temperature range [°F] [min]

-40 °F

Approval

EAC; LLC CDC TYSK

China RoHS compliance

Out of scope

Coil

No

Cv value [gal/min]

1.16 gal/min

Direction

Straightway

EU RoHS compliance

Yes with exemptions

EU RoHS exemption clause

6(a), 6(c)

Function

NC

In scope of WEEE and contain batteries

No

Inlet connection type

Solder, ODF

Inlet size [in]

1 1/8 in

Kv value [m³/h]

1 m³/h

Manual operation option

No

Max. Working Pressure [bar]

46 bar

Max. Working Pressure [psig]

667 psig

MaxOPD[bar] 10W AC

22 bar

MaxOPD[psi] 10W AC

318 psi

Medium temperature range [°C] [max]

60 °C

Medium temperature range [°C] [min]

-50 °C

Medium temperature range [°F] [max]

140 °F

Medium temperature range [°F] [min]

-40 °F

MinODP [bar]

0.45 bar

MinODP [psi]

6.52 psi

MOPD[bar/psi]

22 bar

Orifice size [mm]

5.6 mm

Outlet connection type

Solder, ODF

Outlet size [in]

1 1/8 in

Packing format

Single pack

Product accessories

Electric valve accessories

Product group

Expansion valves

Product Name Description

Electric expansion valve

Quantity per packing format

1 pc

Rated capacity R22 [kW]

100 kW

REACH Candidate List substances

Lead (CAS no. 7439-92-1)

Refrigerants

R134a; R22; R23; R404A; R407A; R407C; R407F; R407H; R410A; R422B; R422D; R438A; R448A; R449A; R449B; R450A; R452A; R463A; R507A; R513A; R513B; R515A; R515B; R744

SCIP dossier no.

d2e83edf-9926-4553-9f97-cb637e372395

Serviceable

Electric valve spare parts

Type

AKV 15-4

Type designation

Electric expansion valve

UK RoHS compliance

Out of scope
