CẢM BIẾN ÁP SUẤT DANFOSS MBS5100 0-6bar 060N1035

Mã sản phẩm: 060N1035
Thương hiệu: Danfoss
Giá thị trường: 1 đ
Tiết kiệm: 0 đ (0%)
Giá bán: 1 đ
Số lượng:
Đặt hàng qua điện thoại: Mr Thịnh - 0918808005 / 0937250579

Hoặc gửi email: thinhhh79@gmail.com

Cảm biến áp suất Danfoss MBS5100 0-6bar, 4-20mA, G1/4, 24VDC, -40 - 85 °C.

Code: 060N1035

Type: MBS 5100-1811-1DB04

Hãng sản xuất: Danfoss

Bảo hành: 12 tháng



Tính năng:

Chuyên dụng trong hàng hải và tàu biển



The ship approved high accuracy pressure transmitter MBS 5100 is designed for use in almost all marine applications, and offers a reliable pressure measurement, even under harsh environmental conditions.
The pressure transmitter programme in block design is approved according to LR, DNV, GL, RINA, ABS, BV, NKK, PRS, MRS, KRS requirements, and covers a 4-20 mA output signal, absolute and gauge (relative) versions, measuring ranges from 0-1 to 0-600 bar, zero point and span adjustment, plug connection and female/flange pressure connections.
Excellent vibration stability, robust construction, and a high degree of EMC/EMI protection equip the pressure transmitter to meet the most stringent industrial requirements.

4 - 20 mA output signal

Operating temperature -40 to 85° C

Measuring range 0 - 600 bar

Pressure connect G ¼ female

Available with all relevant marine approvals

Designed to meet the strict demands in marine equipment

Characteristic

Value

Type MBS 5100
Weight 0.372 Kg
- common PIN 2
+ supply PIN 1
Accuracy, max. +/- FS [%] 0,30 %
Accuracy, typical +/- FS [%] 0,1 %
Adj. zero point and span Yes
Ambient temperature [°C] -40 - 85 °C
Ambient temperature range [°F] -40 - 185 °F
Compensated temp. range [°C] 0 - 80 °C
Compensated temp. range [°F] 32 - 176 °F
EAN 5702423059546
Electrical connection type Pg 11, EN 175301-803-A, Male and Female
Enclosure rating IP65
Flush diaphragm No
Intrinsically safe No
Medium temperature range [°C] -40 - 85 °C
Medium temperature range [°F] -40 - 185 °F
Output signal type 4 - 20 mA
Overload pressure max. [bar] 20,0 bar
Packing format Multi pack
Pressure connection G 1/4
Pressure connection notes With flange
Pressure connection standard ISO 228-1
Pressure connection type G - 1/4 Female
Pressure range [bar] 0,00 - 6,00 bar
Pressure range [kPa] 0,0 - 600,0 kPa
Pressure unit reference Gauge (relative)
Pulse-snubber No
Quantity per packing format 12 PC
Response time max. [ms] 4 ms
Specification key MBS 5100-1811-1DB04
Supply voltage [V] d.c. 10,00 - 32,00 V
Test Signal PIN 3
