BIẾN TẦN DANFOSS VLT® AutomationDrive FC-302 5.5KW - C/N 131B0002

Product View (Switch)

GLBL

Global (Standard)

Product Group

FC-

VLT® AutomationDrive FC-

Series

302

302

Power Rating

P5K5

(P5K5) 5.5 KW / 7.5 HP

Phase

T

Three phase

Mains Voltage

5

380 - 500 VAC

Enclosure

E20

(E20) IP20 / Chassis

RFI Filter

H1

(H1) RFI Class A1/B (C1)

Brake - Safe Stop

X

No brake chopper

LCP

X

No Loc. Cont. Panel

Coating PCB

X

Not coated PCB

Mains Option

X

No Mains Option

Adaptation A

X

Standard Cable Entries

Adaptation B

X

No adaptation

Software Release

SXXX

Latest release std. SW.

Software Language Pack

X

Standard Language Pack

A Option

AX

No A Option

B Option

BX

No B Option

C0 Option MCO

CX

No C0 option

C1 Option

X

No C1 option

C Option Software

XX

No software option

D Option

DX

No D option

Frame Size

A3

A3

Typecode Part 1

FC-302P5K5T5E20H1XXX

Typecode Part 2

XXXSXXXXAXBXCXXXXDX

Product Catalog

NO_VIEW

NO VIEW

Power 160% (HO) [KW]

5.5

Height [mm]

268,0

Width w/ no C options [mm]

130,0

Depth [mm]

205,0

Depth with Option A/B [mm]

220,0

kVA

9.01

Power Loss HO [W]

187

Power Loss HO [W]

187

Continuous Current (HO) [A]

13

Intermittent Current (HO) [A]

20.8

Continuous Current (HO) [A]

11

Intermittent Current (HO) [A]

17.6

Calculated Gross Weight [kg]

7.1

Calculated Net Weight [kg]

6.8

Material Gross Weight

7.12

Material Net Weight

6.53

Vendor

ERR01

Cannot Determine Vendor

Modelcode01

FC-302P5K5T5E20H1XXX

Modelcode02

XXXSXXXXAXBXCXXXXDX
