PHỤ TÙNG VAN DANFOSS SOLENOID COIL BA115A 115V C/N 042N7512

Mã sản phẩm: 042N7512

Thương hiệu: Danfoss

Giá thị trường: 1 đ

Tiết kiệm: 0 đ (0%)

Giá bán: 1 đ

Số lượng:

Đặt hàng qua điện thoại: Mr Thịnh - 0918808005 / 0937250579

Hoặc gửi email: thinhhh79@gmail.com

PHỤ TÙNG VAN DANFOSS SOLENOID COIL BA115A 115V C/N 042N7512

Type: BA115A, Supply voltage [V] AC: 115, Enclosure rating IP: IP00, Coil connection: DIN Spade, Actuator size: 13.5 mm

Gross weight	0.17 kg
Net weight	0.15 kg
EAN	5702423013104
Actuator size	13.5 mm
Ambient temperature range [°C] [Max]	40 °C
Ambient temperature range [°C] [Min]	-40 °C
Ambient temperature range [°F] [Max]	104 °F
Ambient temperature range [°F] [Min]	-40 °F
Coil connection	DIN Spade
Coil design standard	VDE 0580
Coil fastening	Nut and snap
Coil winding insulation class	Class H to IEC 85
Colour	Blue
Duty rating	Continuous
Electrical connection	DIN Spade
Electrical connection size	6.3 mm x 0.8 mm
Electrical connection standard	EN175301-803
Electrical connector	3 x spades
Enclosure rating IP	IP00
Frequency [Hz]	50 Hz
Packing format	Multi pack
Parts included	Nut Snap fastener
Parts Program name	EV210B EV220B 15 - 50 EV220B 6 - 22 EV220B 65 - 100 EV310B
Power consumption 50Hz [VA]	18 VA
Power consumption [W] 50Hz	9 W
Product accessories	Solenoid coil accessories
Product group	Solenoid valves
Product name	Solenoid coil
Quantity per packing format	45 pc
Rel. Humidity [% RH] [Max]	97 %
Rel. Humidity [% RH] [Min]	0 %
Rel. Humidity conditions	Non-condensation
Serviceable	No
Supply voltage 50Hz Max [V]	115 V
Supply voltage [V] a.c.	115 V
Supply voltage [V] AC	115 V
Type	BA115A
Type designation	BA115A
