PHỤ TÙNG VAN DANFOSS SOLENOID COIL BA400A 400V C/N 042N7504

Mã sản phẩm: 042N7504

Thương hiệu: Danfoss

Giá thị trường: 1 đ

Tiết kiệm: 0 đ (0%)

Giá bán: 1 đ

Số lượng:

Đặt hàng qua điện thoại: Mr Thịnh - 0918808005 / 0937250579

Hoặc gửi email: thinhhh79@gmail.com

PHỤ TÙNG VAN DANFOSS SOLENOID COIL BA400A 400V C/N 042N7504

Type: BA400A, Enclosure rating IP: IP00, Coil connection: DIN Spade, Actuator size: 13.5 mm

Gross weight	0.17 kg
Net weight	0.16 kg
EAN	5702423021895
Actuator size	13.5 mm
Ambient temperature range [°C] [Max]	40 °C
Ambient temperature range [°C] [Min]	-40 °C
Ambient temperature range [°F] [Max]	104 °F
Ambient temperature range [°F] [Min]	-40 °F
Coil connection	DIN Spade
Coil design standard	VDE 0580
Coil fastening	Nut and snap
Coil winding insulation class	Class H to IEC 85
Colour	Blue
Duty rating	Continuous
Electrical connection	DIN Spade
Electrical connection size	6.3 mm x 0.8 mm
Electrical connection standard	EN175301-803
Electrical connector	3 x spades
Enclosure rating IP	IP00
Frequency [Hz]	50/60 Hz
Packing format	Multi pack
Parts included	Nut Snap fastener
Parts Program name	EV210B EV220B 15 - 50 EV220B 6 - 22 EV220B 65 - 100 EV310B
Power consumption 50Hz [VA]	22 VA
Power consumption 60Hz [VA]	23 VA
Power consumption [W] 50Hz	12 W
Power consumption [W] 60Hz	13 W
Product accessories	Solenoid coil accessories
Product group	Solenoid valves
Product name	Solenoid coil
Quantity per packing format	45 pc
Rel. Humidity [% RH] [Max]	97 %
Rel. Humidity [% RH] [Min]	0 %
Rel. Humidity conditions	Non-condensation
Serviceable	No
Supply voltage 50Hz Max [V]	400 V
Supply voltage 50Hz Min [V]	380 V
Supply voltage 60Hz Max [V]	440 V
Type	BA400A
Type designation	BA400A
