MÁY BIẾN TẦN DANFOSS FC-302P5K5T5E20H1BGXXXXSXXXXAXBXCXXXXDX - C/N 131B0051

Gross weight

7.516 Kilogram

Net weight

6.51 Kilogram

Volume

27.246 Liter

EAN

5702427094444

Product Group

FC-

VLT^® AutomationDrive FC-

Series

302

302

Power Rating

P5K5

(P5K5) 5.5 KW / 7.5 HP

Phase

T

Three phase

Mains Voltage

5

380 - 500 VAC

Enclosure

E20

(E20) IP20 / Chassis

RFI Filter

H1

(H1) RFI Class A1/B (C1)

Brake - Safe Stop

B

Brake chopper

LCP

G

Graphical Loc. Cont. Panel

Coating PCB

X

Not coated PCB

Mains Option

X

No Mains Option

Adaptation A

X

Standard Cable Entries

Adaptation B

X

No adaptation

Software Release

SXXX

Latest release std. SW.

Software Language Pack

X

Standard Language Pack

A Option

AX

No A Option

B Option

BX

No B Option

C0 Option MCO

CX

No C0 option

C1 Option

X

No C1 option

C Option Software

XX

No software option

D Option

DX

No D option

Frame Size

A3

A3

Modelcode01

FC-302P5K5T5E20H1BGX

Modelcode02

XXXSXXXXAXBXCXXXXDX

Power 160% (HO) [KW]

5.5

5.5

Power Loss HO [W]

187

187

Power Loss HO [W]

187

187

kVA

9.01

9.01

Continuous Current (HO) [A]

13

13

Intermittent Current (HO) [A]

20.8

20.8

Continuous Current (HO) [A]

11

11

Intermittent Current (HO) [A]

17.6

17.6

Height [mm]

268,0

268,0

Width w/ no C options [mm]

130,0

130,0

Width w/ two C options [mm]

190,0

190,0

Depth [mm]

205,0

205,0

Depth with Option A/B [mm]

220,0

220,0

Calculated Gross Weight [kg]

7.516

Calculated Net Weight [kg]

6.51

ECCN EU

Y901

Y901

ECCN US

3A999.a

3A999.a
