BỘ ĐIỀU KHIỂN THIẾT BỊ LÀM LẠNH DANFOSS EKC 302D - C/N 084B4164

Gross weight

0.382 Kilogram

Net weight

0.317 Kilogram

Volume

1.036 Liter

EAN

5702428406987

Type

EKC 302D

Product group

Evaporator and room control

Product Name Description

Refrig appliance control (TXV)

Analog inputs (AI) [pc]

3 pc

Application area

Temperature control

Approval

C-TICK; CE; CMIM; EAC

CE mark

Yes

China RoHS compliance

Yes with exemptions

Communication type

MODBUS; Optional LON; Optional MODBUS

Contains batteries

No

Controller type

Refrig. Controller (Temp)

Digital inputs (DI) [pc]

2 pc

Digital outputs (DO) [pc]

4 pc

Display - option

EKA 163A; EKA 164A

Display on front

Yes

Division

25

EU RoHS compliance

Yes with exemptions

EU RoHS exemption clause

6(c); 7(a); 7(c)-I

Frequency [Hz]

50/60 Hz

Function

Comp.,Defrost,Fan,Alarm,More f

Further information

Alarm= Light or Railheat

Identical product

084B4664

Number of Compressors max.

1 pc

Number of Evaporators max.

1 pc

Number of Sensor inputs

3 pc

Other RoHS documentation

EAEU RoHS

Packing format

Multi pack

PFAS content [Yes/No]

No

Power consumption [VA]

2.3 VA

Product accessories

Electron. control accessories

Quantity per packing format

20 pc

REACH Candidate List substances

Lead (CAS no. 7439-92-1)
Lead titanium zirconium oxide (CAS no. 12626-81-2)
2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol (CAS no. 79-94-7)

SCIP dossier no.

6f7724fd-5e3d-47e7-9447-7928a5c799a4

SCIP dossier product name

EKC 302D/AKCC 350

Sensor type

Temp.Sensors

Serviceable

No

Supply voltage [V] AC

230 V

Temp. sensor support

NTC-M2020; PTC 1000; Pt 1000

Valve output type

EVR (TXV)
