VAN ĐIỆN TỪ DANFOSS EV310A, Function: NC, G, 1/4, 0.04 m³/h, FKM - C/N 032H819532

Gross weight

0.224 Kilogram

Net weight

0.216 Kilogram

Volume

0.114 Liter

EAN

5702428492553

Type

EV310A

Product group

Solenoid valves

Product Name Description

Solenoid valve

Actuator

A

Actuator size

9 mm

Actuator size [in]

0.35 in

Actuator system [mm]

9 mm

Ambient temperature max. [°C]

50 °C

Ambient temperature max. [°F]

122 °F

Application

Open

Approval

CE; UKCA

Body material

Brass

CE mark

Yes

China RoHS compliance

Out of scope

Coil type

AM

Connection Internal/External

Internal

Connection material

Brass

Connection size [in]

1/4

Connection standard

ISO 228-1

Connection type

G

Contains batteries

No

Cv value [gal/min]

0.05 gal/min

Differential pressure [bar] [max]

20 bar

Differential pressure [bar] [min]

0 bar

Differential pressure [psi] [max]

290 psi

Differential pressure [psi] [min]

0 psi

EEE category

5 small equipment (any external dimension < 50 cm)

Electrical connection

Spade DIN 43650-A

Enclosure rating IP

IP00

Est. time to close, water [ms]

10 ms

Est. time to open, water [ms]

10 ms

EU RoHS compliance

Yes with exemptions

EU RoHS exemption clause

6(c)

Flow direction indicator

Engraved A-P-R

Fluid Group

1

Frequency [Hz]

50/60 Hz

Function

NC

In scope of WEEE

Yes

Kv value [m³/h]

0.04 m³/h

Max media viscosity [cSt]

20 cSt

Max. test pressure [bar]

30 bar

Max. test pressure [psig]

435 psig

Max. Working Pressure [bar]

20 bar

Max. Working Pressure [psig]

290 psig

Media recommendations

Oil,Comp.Air,Vacuum

Media tolerance comments

Neutral media

Medium temperature range [°C] [max]

100 °C

Medium temperature range [°C] [min]

-10 °C

Medium temperature range [°F] [max]

212 °F

Medium temperature range [°F] [min]

14 °F

Number of ways

3/2

Operation

Direct-operated

Orifice size [mm]

1.2 mm

Orifice size fraction [in]

3/64 in

Packing format

Multi pack

Parts Program name

EV310A

Power consumption [W] 50Hz

9.5 W

Power consumption [W] 60Hz

6.5 W

Product accessories

Solenoid coil accessories; Solenoid valve accessories

Quantity per packing format

16 pc

REACH Candidate List substances

Lead (CAS no. 7439-92-1)

SCIP dossier no.

049058ad-6d73-4ec9-9d2b-b574054e817d

SCIP dossier product name

EV310A - solenoid valve

Seal Material

FKM

Serviceable

Solenoid valve spare parts

Specification key

EV310A 1.2B G 14F NC000 AM230C

Supply voltage 50Hz Max [V]

230 V

Supply voltage 60Hz Max [V]

230 V

Supply voltage [V] AC

230 V

Type designation

EV310A 1.2
